Convertible top fitting stainless steel/nylon - swivel round, heavy-duty design

This heavy-duty swivel convertible top fitting with a round nylon base plate and stainless steel mounting is the professional solution for the highest loads. Featuring a 4-bolt fastening for maximum stability – ideal for premium-quality sprayhoods, bimini tops, and folding convertible tops.

Product features

• Heavy-duty design - designed for maximum loads
• 4-bolt mounting - Maximum stability through 4 mounting points
• Stainless steel A4/Nylon - Corrosion-resistant with nylon backing plate
• Swiveling - Movable mount for optimal angle adjustment
• Round base plate - Ø 64mm for large contact surface
• Premium quality - High-quality workmanship for professional applications

Technical data

Application areas

• Heavy-duty deck fixing for sprayhoods
• Bimini top with high load capacity
• Convertible top fixings for large yachts
• Sunshade brackets for heavy-duty use
• Convertible top frame with maximum stability requirements
• All applications with heavy convertible top fittings

Heavy-duty design - Maximum stability

4-bolt mounting: Unlike standard fittings with 2 or 3 mounting points, this heavy-duty version offers 4 bolts on a 44mm bolt circle. This ensures maximum stability and load-bearing capacity.

Large contact area: The round base plate with an outer diameter of 64mm optimally distributes the forces onto the deck and prevents damage.

For maximum loads: Ideal for large canopies, heavy constructions or applications with high wind and sea conditions.

Material combination - stainless steel and nylon

Stainless steel A4 mount: The movable mount made of stainless steel A4 ensures maximum stability and corrosion resistance in maritime applications.

Round nylon support plate: UV-resistant, corrosion-resistant, and protects the deck. The large round plate (Ø 64mm) optimally distributes the load.

Premium quality: The combination of high-quality stainless steel and nylon offers optimal properties for continuous use under the highest loads.

Swivel function

Movable mount: The stainless steel mount is pivotally mounted, allowing the convertible top frame to be optimally positioned.

Flexible angle adjustment: Thanks to the swivel function, the canopy can always be mounted in the optimal position, regardless of the deck construction.

Technical details

Øa (outer diameter): 64 mm - Large round base plate for optimal force distribution.

Ø Pitch circle diameter: 44 mm - Diameter of the pitch circle for the 4 mounting bolts.

Fork width: 7 mm - For secure mounting of the convertible top frame.

Bolt diameter: 6 mm - For a stable connection.

4-bolt fastening: Maximum stability through 4 fastening points.

Assembly and use

The round nylon base plate is attached to the deck with four bolts on a 44mm bolt circle. The swiveling mount allows for optimal alignment of the stainless steel fork. The canopy frame is inserted into the mount and secured with a 6mm bolt.

• Mount the base plate - Attach the round nylon plate to the deck with 4 bolts.
• Align - Use swivel mount for optimal positioning
• Install the convertible top frame - insert the tube into the stainless steel holder.
• Secure - Fix with 6 mm bolts

Advantages

• Heavy-duty design - designed for maximum loads
• 4-bolt fastening - Maximum stability
• Large contact surface - Ø 64mm optimally distributes forces
• Swiveling - Movable mount for optimal angle adjustment
• Premium quality - High-quality workmanship
• Professional quality - proven in maritime use

Ideal for

• Large sailing yachts with heavy sprayhoods
• Motorboats with large bimini tops
• Boats subjected to high stresses from wind and waves
• Professional boat builders and sailmakers
• Applications with maximum stability requirements
• All heavy-duty convertible top systems
